Name: Motor Water Cooling Radiator
Brand: Shandong Ouruian Electric Co., Ltd.
Availability: InStock

Motor Water Cooling Radiator

Ouruian’s precision-engineered water cooling radiators ensure optimal thermal regulation for high-performance motors, reducing heat-related failures by up to 70%. Made from aerospace-grade aluminum with patented turbulent-flow fin design, our radiators maximize heat dissipation while maintaining compact, lightweight construction. Trusted by EV, industrial automation, and renewable energy leaders for continuous, reliable cooling under extreme loads.

Specifications of Motor Water Cooling Radiator

Self-circulating Water Chiller

Type	Water tank volume(L)	Rated flow Q (m³/h)	Operating fux(L/min)	Water pump power (kW)	Fan power (kW)	Heat dissipation power(kW)	Adapted PMSM power(kW)	Length×Width ×Height(mm)	Weight (kg)


CL-300	300	6	50	4		20	P≤160	1350×1100×1150	545
CL-500	500	6	65	4		40	P≤315	1350×1100×1150	590
CL-700	700	8	100	5.5		65	P≤630	1500×1300×1350	740
CL-900	900	10	150	4	4	90	P≤1000	2000×1200×1300	950
CL-1000	1000	15	200	5.5	5.5	120	P≤1250	1700×1200×1730	1100

General water quality standards for cooling water(GB/T 19923):

Item	Cooling water quality requirements
PH	7-8.5
Suspended solids(mg/L)	≤10
Turbidity(NTU)	≤5
Total alkalinity(calculated as CaCO₃/mg/L)	≤250
Sulfate(mg/L)	≤250
Ammonia nitrogen(mg/L in N)	≤10
Total dissolved solids(mg/L)	≤1000
Petroleum(mg/L)	≤1

Notes:

To ensure safety,please read this chapter carefully before using the water chiller and follow the requirements during transportation, installation, operation, commissioning, and maintenance.
Users should pay attention to the ambient temperature around the water chiller during winter, which should not be lower than 0℃, to prevent the cooling water from freezing and causing damage to the water chiller. Special treatment is required under extremely cold conditions before use.
When using the water chiller, it is necessary to ensure that the water outlet is unobstructed and not blocked to avoid excessive water pressure and damage to the water chiller.
When users need to shut down and disconnect the power cord, special tools must be used to discharge the wiring terminals of the water chiller to avoid electric shock.
The introduced cable core wire must be tightly fixed with a wiring pressure plate to prevent cable movement, otherwise it is easy to have a short circuit, causing discharge and explosion.
It is strictly prohibited to open the lid with electricity.

Operation Steps:

Before starting up, fill the water tank with water(about 90%) and check if all interfaces are properly installed.
Check if the two DN32 ball valves have been opened(handle in the direction of the pipeline).
Check the pressure reducing valve and ensure that the adjustment bolts of the pressure reducing valve are tightened (note: tightened before leaving the factory).
Power on the motor, check if the motor direction is correct, and the cooling fan is in the suction mode.
After starting up, open the DN10 ball valve on the filter until water flows out and close it.
After 10 minutes of normal operation, when the water level in the water tank no longer drops, fill the tank with water and it can run normally.
